Descripción
FEATURES:
Reliability:
- True double-conversion
- DSP Technology guarantees high reliability
- Galvanic isolation
- Separated Bypass on each UPS module
- IP54 (Optional IP66)
Efficiency:
- 94% AC Mode, 97% ECO Mode
- THDi 3% (Non linear load)
- Output Power Factor 1
Flexibility:
- Modular Design N+1
- Hot-swappable modules
- Internal Batteries
- Configurations: Single Phase, Three Phase, Single Phase/Three Phase
- Easy maintenance
- Customized system
Modular and Hot-Swappable design: Easy power expansion, installation and maintenance
Modar is applied patented modular design to enhance the flexibility of power expansion and maintenance. The power module can be easily removed out from cabinet without disconnecting all wires. This simplifies the maintenance process and reduce the cost effectively.
Custom Design
MODAR UPS can easily form a complete system based on customer’s demand. It possible customized:
Voltage configuration: 1Phase/1Phase, 3Phase/3Phase, 3Phase/1Phase
Galvanic Isolation: Input, Output and Bypass
Modular Configuration: N+1
Parallel Operation: Up to 10 units
Backup Time and Batteries: AGM, OPZV, NICD
Communication: SNMP, Modbus, Profibus
Dry Contacts: Alarms
IP Protection: IP42, IP54, IP66
Output power factor 1.0
For critical applications, the modular UPS with output power factor 1.0 ensures higher efficiency and advanced performance.
50Hz/60Hz frequency converter mode
Lock output frequency at 50Hz or 60Hz to suit power sensitive equipments.
ECO mode operation for energy saving
ECO mode improves the efficiency up to 97% to cut energy usage & cost. In this mode, loads are supplied by the mains directly. While mains failure, the UPS will constantly supply the power to the connected device without any interruption.
Emergency power off function (EPO)
In case of any emergency and fire, the EPO control mechanism can instantly shut down the system.
Generator compatible
This UPS can accept generator as power source and still convert perfect power to the connected loads.
